1. Primarily used at the output side of equipment with motors as the load.
2. Effectively filters common-mode interference at the equipment output end.
3. Various voltage ratings available.
4. Low leakage current model available.

Rated voltage: 440VAC, 520VAC, 690VAC
Rated current: 5–1600A
Operating frequency: 0–60Hz
Connection method: European-style terminal, copper busbar
Operating temperature range: –25°C to 100°C
Applicable standards: UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939, GB15287

Typical Application Scenarios:
1. Output side of variable frequency drive systems;
2. Output side of inverter power supplies;
3. Input side of transmission equipment and inductive loads.
